from functools import singledispatch
import numpy as np
import pytensor.tensor as pt
from numpy.lib.array_utils import normalize_axis_tuple
from pytensor.graph import Op
from pytensor.tensor import TensorLike, TensorVariable
from pymc.logprob.transforms import (
ChainedTransform,
CircularTransform,
IntervalTransform,
LogOddsTransform,
LogTransform,
SimplexTransform,
Transform,
)
__all__ = [
"Chain",
"CholeskyCorrTransform",
"CholeskyCovPacked",
"CholeskyCovTransform",
"Interval",
"Transform",
"ZeroSumTransform",
"circular",
"log",
"log_exp_m1",
"logodds",
"ordered",
"simplex",
"sum_to_1",
]
@singledispatch
def _default_transform(op: Op, rv: TensorVariable):
"""Return default transform for a given Distribution `Op`."""
return None
[docs]
class LogExpM1(Transform):
name = "log_exp_m1"
[docs]
def backward(self, value, *inputs):
return pt.softplus(value)
[docs]
def forward(self, value, *inputs):
"""Inverse operation of softplus.
y = Log(Exp(x) - 1)
= Log(1 - Exp(-x)) + x
"""
return pt.log(1.0 - pt.exp(-value)) + value
[docs]
def log_jac_det(self, value, *inputs):
return -pt.softplus(-value)
[docs]
class Ordered(Transform):
"""
Transforms a vector of values into a vector of ordered values.
Parameters
----------
positive: If True, all values are positive. This has better geometry than just chaining with a log transform.
ascending: If True, the values are in ascending order (default). If False, the values are in descending order.
"""
name = "ordered"
[docs]
def __init__(self, positive=False, ascending=True):
self.positive = positive
self.ascending = ascending
[docs]
def backward(self, value, *inputs):
if self.positive: # Transform both initial value and deltas to be positive
x = pt.exp(value)
else: # Transform only deltas to be positive
x = pt.empty(value.shape)
x = pt.set_subtensor(x[..., 0], value[..., 0])
x = pt.set_subtensor(x[..., 1:], pt.exp(value[..., 1:]))
x = pt.cumsum(x, axis=-1) # Add deltas cumulatively to initial value
if not self.ascending:
x = x[..., ::-1]
return x
[docs]
def forward(self, value, *inputs):
if not self.ascending:
value = value[..., ::-1]
y = pt.empty(value.shape)
y = pt.set_subtensor(y[..., 0], pt.log(value[..., 0]) if self.positive else value[..., 0])
y = pt.set_subtensor(y[..., 1:], pt.log(value[..., 1:] - value[..., :-1]))
return y
[docs]
def log_jac_det(self, value, *inputs):
if self.positive:
return pt.sum(value, axis=-1)
else:
return pt.sum(value[..., 1:], axis=-1)
class SumTo1(Transform):
"""
Transforms K - 1 dimensional simplex space (K values in [0, 1] that sum to 1) to a K - 1 vector of values in [0, 1].
This transformation operates on the last dimension of the input tensor.
"""
name = "sumto1"
def backward(self, value, *inputs):
remaining = 1 - pt.sum(value[..., :], axis=-1, keepdims=True)
return pt.concatenate([value[..., :], remaining], axis=-1)
def forward(self, value, *inputs):
return value[..., :-1]
def log_jac_det(self, value, *inputs):
y = pt.zeros(value.shape)
return pt.sum(y, axis=-1)
class CholeskyCorrTransform(Transform):
r"""Map an unconstrained real vector to the Cholesky factor of a correlation matrix.
Constrained space: ``(n, n)`` lower-triangular Cholesky factor ``L`` of a
correlation matrix, with unit-norm rows (so ``L @ L.T`` has ones on the diagonal).
Unconstrained space: ``(n*(n-1)/2,)`` flat real vector packed in row-major
strictly-lower-triangular order.
The transform composes three steps:
1. Scatter the flat vector into the strictly lower-triangular positions of an
``(n, n)`` matrix and set the diagonal to 1.
2. Normalize each row to unit L2 norm, producing the Cholesky factor ``L``.
The Jacobian of the composite map uses the diagonal of the normalized factor:
.. math::
\log |J| = \sum_{k=0}^{n-1} (k+2)\,\log L_{kk}
= -\tfrac12 \sum_{k=0}^{n-1} (k+2)\,\log\!\bigl(1 + \|r_k\|^2\bigr)
where :math:`r_k` are the off-diagonal elements placed in row *k*.
References
----------
.. [1] Lewandowski, D., Kurowicka, D., & Joe, H. (2009).
Generating random correlation matrices based on vines and extended onion method.
Journal of Multivariate Analysis, 100(9), 1989–2001.
.. [2] Stan Development Team. Stan Functions Reference. Section on LKJ / Cholesky correlation.
"""
name = "cholesky_corr"
def __init__(self, n, upper: bool = False):
if upper:
raise NotImplementedError("upper=True is not supported")
self.n = n
self.upper = upper
self.tril_idxs = pt.tril_indices(n, -1)
super().__init__()
def forward(self, chol_corr_matrix: TensorLike, *inputs):
chol_corr_matrix = pt.as_tensor_variable(chol_corr_matrix)
# Divide each row by its diagonal element to undo the normalization.
diag = pt.diagonal(chol_corr_matrix, axis1=-2, axis2=-1)[..., None]
unconstrained = chol_corr_matrix / diag
# The strictly lower-triangular elements (row-major) are the free parameters.
return unconstrained[..., self.tril_idxs[0], self.tril_idxs[1]]
def backward(self, unconstrained_vector: TensorLike, *inputs):
unconstrained_vector = pt.as_tensor_variable(unconstrained_vector)
n = self.n
# Scatter into the strictly-lower-triangular positions of an (n, n) matrix.
L = pt.zeros((*unconstrained_vector.shape[:-1], n, n), dtype=unconstrained_vector.dtype)
L = L[..., self.tril_idxs[0], self.tril_idxs[1]].set(unconstrained_vector)
# Set diagonal to 1 (before normalization).
diag_idx = pt.arange(n)
L = L[..., diag_idx, diag_idx].set(1)
# Normalize each row to unit L2 norm.
L /= pt.linalg.norm(L, axis=-1, ord=2)[..., None]
return L
def log_jac_det(self, unconstrained_vector: TensorLike, *inputs) -> TensorVariable:
unconstrained_vector = pt.as_tensor_variable(unconstrained_vector)
n = self.n
dtype = unconstrained_vector.dtype
# Compute per-row sum of squares of the off-diagonal elements directly,
# without constructing the full normalized matrix.
sq = unconstrained_vector**2
row_sums_sq = pt.zeros((*unconstrained_vector.shape[:-1], n), dtype=dtype)
row_sums_sq = pt.inc_subtensor(row_sums_sq[..., self.tril_idxs[0]], sq)
# After setting diagonal to 1 and normalizing, diag_k = 1/sqrt(1 + row_sums_sq_k).
log_diag = pt.cast(-0.5, dtype) * pt.log1p(row_sums_sq)
coeffs = pt.arange(2, 2 + n, dtype=dtype)
return pt.sum(coeffs * log_diag, axis=-1)
[docs]
class CholeskyCovPacked(Transform):
"""Transforms the diagonal elements of the LKJCholeskyCov distribution to be on the log scale."""
name = "cholesky-cov-packed"
[docs]
def __init__(self, n):
"""Create a CholeskyCovPack object.
Parameters
----------
n : int
Number of diagonal entries in the LKJCholeskyCov distribution.
"""
self.diag_idxs = pt.arange(1, n + 1).cumsum() - 1
[docs]
def backward(self, value, *inputs):
return pt.set_subtensor(value[..., self.diag_idxs], pt.exp(value[..., self.diag_idxs]))
[docs]
def forward(self, value, *inputs):
return pt.set_subtensor(value[..., self.diag_idxs], pt.log(value[..., self.diag_idxs]))
[docs]
def log_jac_det(self, value, *inputs):
return pt.sum(value[..., self.diag_idxs], axis=-1)
class CholeskyCovTransform(Transform):
r"""Map an unconstrained real vector to a symmetric positive-definite (SPD) matrix.
Constrained space: ``(n, n)`` SPD matrix ``X``.
Unconstrained space: ``(n*(n+1)/2,)`` flat real vector packed in row-major
lower-triangular order.
The transform composes two steps:
1. Reshape the flat vector into a lower-triangular matrix ``L``, exponentiating
the diagonal entries (so ``L_kk > 0``).
2. Form ``X = L @ L.T``, the SPD matrix.
The lower-triangular ``L`` produced inside ``backward`` is tagged with
``lower_triangular = True`` so PyTensor's ``cholesky_ldotlt`` rewrite eliminates
any subsequent ``cholesky(L @ L.T)`` calls (e.g. inside a Cholesky-based
``Wishart.logp``), avoiding a redundant decomposition at runtime.
The Jacobian of the composite map (free reals :math:`\to L \to L L^\top`) is
.. math::
|J| = \prod_k L_{kk} \cdot 2^n \cdot \prod_k L_{kk}^{n-k+1}
= 2^n \cdot \prod_k L_{kk}^{n-k+2}.
With :math:`y_{kk} = \log L_{kk}` the diagonal entries of the unconstrained
vector, the log-Jacobian is
.. math::
\log |J| = n \log 2 + \sum_{k=1}^{n} (n - k + 2)\, y_{kk}.
Examples
--------
.. code-block:: python
import numpy as np
import pytensor.tensor as pt
from pymc.distributions.transforms import CholeskyCovTransform
tr = CholeskyCovTransform(n=3)
unconstrained = pt.as_tensor(np.array([0.0, 0.5, 0.0, 0.2, -0.1, 0.0]))
Sigma = tr.backward(unconstrained)
# Sigma is a (3, 3) SPD matrix.
"""
name = "cholesky-cov"
def __init__(self, n):
"""Create a CholeskyCovTransform.
Parameters
----------
n : int or TensorLike
Side length of the SPD matrix.
"""
self.n = n
self.diag_idxs = pt.arange(1, n + 1).cumsum() - 1
self.tril_idxs = pt.tril_indices(n)
def backward(self, value, *inputs):
value = pt.as_tensor_variable(value)
# Exponentiate the diagonal entries so L has positive diagonal.
value_pos = value[..., self.diag_idxs].set(pt.exp(value[..., self.diag_idxs]))
# Scatter into a (..., n, n) lower-triangular matrix L.
n = self.n
L_shape = (*value.shape[:-1], n, n)
L = pt.zeros(L_shape, dtype=value.dtype)
L = L[..., self.tril_idxs[0], self.tril_idxs[1]].set(value_pos)
# Tag L as lower-triangular so cholesky(L @ L.mT) → L is rewritten away.
L.tag.lower_triangular = True
return L @ L.mT
def forward(self, value, *inputs):
value = pt.as_tensor_variable(value)
L = pt.linalg.cholesky(value)
flat = L[..., self.tril_idxs[0], self.tril_idxs[1]]
# log the diagonal entries to make them unconstrained.
return flat[..., self.diag_idxs].set(pt.log(flat[..., self.diag_idxs]))
def log_jac_det(self, value, *inputs):
value = pt.as_tensor_variable(value)
n = self.n
log_diag = value[..., self.diag_idxs]
coeffs = pt.arange(n + 1, 1, -1).astype(value.dtype)
return n * pt.log(2.0) + pt.sum(coeffs * log_diag, axis=-1)
Chain = ChainedTransform
simplex = SimplexTransform()
simplex.__doc__ = """
Instantiation of :class:`pymc.logprob.transforms.SimplexTransform`
for use in the ``transform`` argument of a random variable."""
logodds = LogOddsTransform()
logodds.__doc__ = """
Instantiation of :class:`pymc.logprob.transforms.LogOddsTransform`
for use in the ``transform`` argument of a random variable."""
[docs]
class Interval(IntervalTransform):
"""Wrapper around :class:`pymc.logprob.transforms.IntervalTransform` for use in the ``transform`` argument of a random variable.
Parameters
----------
lower : int or float, optional
Lower bound of the interval transform. Must be a constant finite value.
By default (``lower=None``), the interval is not bounded below.
upper : int or float, optional
Upper bound of the interval transform. Must be a constant finite value.
By default (``upper=None``), the interval is not bounded above.
bounds_fn : callable, optional
Alternative to lower and upper. Must return a tuple of lower and upper bounds
as a symbolic function of the respective distribution inputs. If one of lower or
upper is ``None``, the interval is unbounded on that edge.
.. warning:: Expressions returned by `bounds_fn` should depend only on the
distribution inputs or other constants. Expressions that depend on nonlocal
variables, such as other distributions defined in the model context will
likely break sampling.
Examples
--------
Create an interval transform between -1 and +1
.. code-block:: python
with pm.Model():
interval = pm.distributions.transforms.Interval(lower=-1, upper=1)
x = pm.Normal("x", transform=interval)
Create a lower-bounded interval transform at 0, using a callable
.. code-block:: python
def get_bounds(rng, size, mu, sigma):
return 0, None
with pm.Model():
interval = pm.distributions.transforms.Interval(bounds_fn=get_bounds)
x = pm.Normal("x", transform=interval)
Create a lower-bounded interval transform that depends on a distribution parameter
.. code-block:: python
def get_bounds(rng, size, mu, sigma):
return mu - 1, None
interval = pm.distributions.transforms.Interval(bounds_fn=get_bounds)
with pm.Model():
mu = pm.Normal("mu")
x = pm.Normal("x", mu=mu, sigma=2, transform=interval)
"""
[docs]
def __init__(self, lower=None, upper=None, *, bounds_fn=None):
if bounds_fn is None:
try:
bounds = tuple(
None if bound is None else pt.constant(bound, ndim=0).data
for bound in (lower, upper)
)
except (ValueError, TypeError):
raise ValueError(
"Interval bounds must be constant values. If you need expressions that "
"depend on symbolic variables use `args_fn`"
)
lower, upper = (
None if (bound is None or np.isinf(bound)) else bound for bound in bounds
)
if lower is None and upper is None:
raise ValueError("Lower and upper interval bounds cannot both be None")
def bounds_fn(*rv_inputs):
return lower, upper
super().__init__(args_fn=bounds_fn)
log_exp_m1 = LogExpM1()
log_exp_m1.__doc__ = """
Instantiation of :class:`pymc.distributions.transforms.LogExpM1`
for use in the ``transform`` argument of a random variable."""
ordered = Ordered()
ordered.__doc__ = """
Instantiation of :class:`pymc.distributions.transforms.Ordered`
for use in the ``transform`` argument of a random variable."""
log = LogTransform()
log.__doc__ = """
Instantiation of :class:`pymc.logprob.transforms.LogTransform`
for use in the ``transform`` argument of a random variable."""
sum_to_1 = SumTo1()
sum_to_1.__doc__ = """
Instantiation of :class:`pymc.distributions.transforms.SumTo1`
for use in the ``transform`` argument of a random variable."""
circular = CircularTransform()
circular.__doc__ = """
Instantiation of :class:`pymc.logprob.transforms.CircularTransform`
for use in the ``transform`` argument of a random variable."""
